Hebei Juliang Technology Co., Ltd. is one of the leading manufacturers and suppliers of 1500w handheld fiber laser welding machine in China. Please feel free to buy CE approved machinery made in China here from our factory. All customized machines are with high quality and competitive price.

You've Used TIG for the Finish. You've Used MIG for Speed. Now Stop Choosing

Most welders face the same trade-off: beautiful but slow, or fast but messy. A stainless steel handrail needs TIG-quality appearance, but production deadlines demand MIG speed. That conflict disappears with one machine.

The 1500W handheld fiber laser welding machine delivers TIG-level weld formation at MIG-level travel speeds. And because heat input stays low, you don't spend time fixing burn-through, warping, or oxidation stains.

The Real Reason Shops Switch to 1500W (It's Not Just Power)

Walk into any small fabrication shop. What do you see? Grinders everywhere. Why? Because MIG leaves spatter. TIG leaves color. Both need cleaning.

Now watch someone use this 1500W handheld fiber laser welding machine. The weld comes out smooth and slightly concave. No spatter. No heat tint on stainless. They set the grinder aside. That single change cuts finishing labor by more than half.

What makes this possible:

Forced air cooling (no water pumps, no antifreeze, no leaks)
1080nm wavelength (consistent across steel, stainless, aluminum)
0–120 mm/s adjustable speed (slow for corners, fast for straights)
≤0.5mm gap tolerance (real parts don't always fit perfectly)

Technical Parameters

No.	Item	Parameter
1	Equipment Name	Handheld Fiber Laser Welding Machine
2	Laser Power	1500W
3	Laser Wavelength	1080nm
4	Fiber Length	10M standard, up to 15M
5	Working Mode	Continuous / Modulated
6	Welding Speed Range	0–120 mm/s
7	Cooling Method	Forced air cooling
8	Operating Temperature	15–35°C
9	Operating Humidity	<70% non-condensing
10	Recommended Thickness	0.5–7mm
11	Gap Requirement	≤0.5mm
12	Working Voltage	AC220V / AC380V

Penetration Data – What 1500W Actually Does

Material	Maximum Penetration
Carbon steel	5.0mm
Stainless steel	5.0mm
Aluminum	4.0mm
Galvanized sheet	4.0mm

One machine welds 1mm sheet without burn-through, and also joins 5mm structural brackets. No second machine. No changeover time.

From the Shop Floor: Where This Machine Pays for Itself Fastest

I've watched a fabricator weld a stainless steel kitchen exhaust hood. TIG took 40 minutes per seam. Then another 15 minutes polishing heat tint. With the 1500W handheld fiber laser welding machine, the same seam took 12 minutes. Zero polishing. He moved to the next hood immediately.

Applications where that math works best:

Industry	Why 1500W Works
Pipe welding	Weld in position, rotate, no reheating
Hardware processing	Quick changeover between small brackets and hinges
Airtight components	Consistent penetration, no pinhole leaks
Electronics enclosures	Thin sheet metal won't warp
Medical device parts	Clean seams pass visual inspection as-welded

One customer's words: "I used to budget 30% of my labor for grinding and finishing. Now it's under 10%. The weld looks finished right off the gun."

Why Air Cooling? (And Why It Matters for You)

Most people assume higher power means water cooling. Not here.

This 1500W handheld fiber laser welding machine uses forced air cooling because 1500W sits at the practical limit where air still works reliably. No water tank. No pump maintenance. No risk of freezing in unheated shops. No coolant leaks onto your workpieces.

What you don't have to do:

Check coolant levels every morning
Replace antifreeze seasonally
Worry about pump failure on a Friday afternoon

You just weld.

Who Builds This Machine – Hebei Juliang Technology Co., Ltd.

We started in CNC cutting in 2014. Portable cutters first. Then gantry systems. By 2018, we had our own factory and the "Xin Juliang" brand.

Laser welding came in 2020. Laser cutting followed in 2022. The same year, we entered international markets and earned:

High-tech enterprise certification

Science and technology-based SME status

Multiple invention patents and utility model patents

By 2025: Listed as a specialized, refined, distinctive, and innovative enterprise. Products now export to Southeast Asia (18% of sales), Africa (23%), Eastern Asia (15%), Europe, and the US.

Certifications you can verify:

CE certificate

Invention Patent Certificate

Utility Model Patent Certificate

Registered trademark "Xinju Liang"

Customer Case: Staircase Fabricator in Southeast Asia

Before: Welding 2mm stainless steel tubes to 3mm plates. TIG was too slow. MIG left spatter on every joint – grinding required on visible handrails.
After: One 1500W handheld fiber laser welding machine
Result: Weld time per joint: 90 seconds → 25 seconds. Grinding: eliminated.
Follow-up: Ordered a second unit within three months.

FAQ

Q: Can 1500W air-cooled run a full 8-hour shift?

A: Yes for typical shop work – weld 10–15 minutes, then move or reposition. If you need continuous welding at maximum power for hours, we'll recommend stepping to a water-cooled 2000W model. Tell us your actual duty cycle. We won't oversell or underspec.

Q: Does 1500W need 380V or 220V?

A: Both work. Single-phase 220V is fine for most shops – no industrial electrician required. 380V three-phase gives more stable input for heavy daily use. Order with your local voltage. We ship both versions.

Q: How long before the handheld gun feels heavy?

A: Most operators run 4–6 hours daily without straps or supports. The torch is balanced, not front-heavy. For overhead or vertical welding all day, add a flexible support arm or neck strap – both available as options.

Stop Grinding. Start Welding.

You already have TIG skills. You already have MIG speed expectations. Now get both from one air-cooled handheld unit.
One 1500W handheld fiber laser welding machine. No water. No spatter. No polishing.
Get a Quote – Tell us your material and thickness. We'll confirm fit.
Request a Sample Weld – Ship us your parts. We weld them. You judge.
Download Full Spec Sheet – Duty cycle charts and dimensional drawings included.
