Hebei Juliang Technology Co., Ltd. is one of the leading manufacturers and suppliers of cnc cutting equipment in China. Please feel free to buy CE approved machinery made in China here from our factory. All customized machines are with high quality and competitive price.
What Is CNC Cutting Equipment?
CNC cutting equipment uses computer-controlled machines and various thermal or mechanical methods to precisely cut metal with consistent results. It's like the difference between using a butter knife and a surgical scalpel for steak, but imagine the "steak" is steel plate and the "scalpel" is a plasma arc, laser, or oxy-fuel flame directed by digital commands. These machines interpret your CAD files, create cutting paths, and perform cuts far more accurately than manual techniques.
Hebei Juliang Technology Co., Ltd. has been manufacturing and supplying CNC cutting equipment since 2018. We understand that each workshop has unique needs regarding materials, production volume, and budget. Consequently, we provide a diverse selection of equipment, from small desktop units to large industrial tables, suitable for plasma, oxy-fuel, and combined cutting processes.
How Does It Actually Work?
At its core, all CNC cutting equipment operates on the same principle: a computer guides a cutting tool along a set path, removing material. However, the specific method varies by process.
Plasma cutting employs ionized gas. Compressed air or other gases pass through a copper nozzle, and an electric arc transforms the gas into plasma exceeding 20,000°C. This plasma jet instantly melts metal on contact, and the forceful gas stream expels the molten material. Plasma is effective on any conductive metal, including carbon steel, stainless steel, aluminum, copper, and brass. For steel thicker than roughly 6mm, plasma cutters typically offer superior cutting speed and edge quality compared to lasers. They also handle materials that are rusted, painted, or reflective more effectively.
Oxy-fuel (flame) cutting, though an older technology, remains essential for specific tasks. It utilizes combustion: a fuel gas mixed with oxygen produces a flame that heats steel to its ignition point. A stream of pure oxygen is then directed at the heated area. This oxygen reacts with the iron in the steel, a process of rapid, controlled oxidation. The resulting chemical reaction generates enough heat to sustain the cut. This method is exclusive to carbon steel but proves more cost-effective for thick plates, up to 200mm or more.
The CNC system orchestrates everything. The control unit interprets G-code instructions derived from your design files. Servo or stepper motors move the gantry along precise linear guides on the X and Y axes. The Z axis manages the torch height, which is automated in more sophisticated systems to adjust for plate warpage and uneven surfaces in real-time.
The cutting table supports the material. Slats hold the plate above a water table or downdraft system designed to capture fumes, sparks, and slag. Certain setups offer submerged cutting, dramatically reducing smoke and noise.
The features of the equipment
Versatile Cutting:Handles plasma, oxy-fuel, and combo setups. Plasma is quick and great for stainless steel and aluminum, while flame is budget-friendly for thick carbon steel. One machine does it all with the right setup.
Precision Cutting: Achieves ±0.05 mm positioning accuracy and ±0.03 mm repeat positioning. This precision means parts like brackets and frames fit perfectly without needing extra work.
Reliable Drive System: Dual-drive servo or stepper motors keep the gantry perfectly synchronized. This ensures consistent power and accurate cuts across the entire workspace.
Affordable Maintenance: Built with a simple design, there are fewer parts to fail. The gear and rack system is reliable and easy to maintain. Ongoing costs are mainly for consumables like electrodes and nozzles, which are affordable and widely available. Predictive maintenance can slash downtime by up to half by spotting problems early.
Simple Setup: Many models arrive fully assembled. Just place the table, level it (takes about 30 mins), hook up power and air, and you're ready to cut. No need for foundations or cranes. Most clients are cutting parts on the same day they receive it.
Uninterrupted Operation: Runs on its own. Load a plate, start the job, and focus on other tasks while it cuts. It's consistent, dependable, and never needs a break.
CE Certified: Meets European safety and quality standards, which is important for international sales and your confidence.
Our services include
Before you buy:
We'll guide you in selecting the best equipment for your production requirements.
We can recommend the appropriate power and current based on your typical material ratios.
We'll confirm your design's compatibility through drawing analysis.
We offer suggestions for factory layouts to optimize workflow.
Installation:
Remote installation support is straightforward with our guide.
We'll perform initial calibration and test runs via video call.
Training:
We provide operator training covering basic operation, maintenance, and troubleshooting.
Training is also available for CNC software programming.
ation of semi-finished food project
Products Description
FAQ
Plasma cuts faster, works on all conductive metals including stainless and aluminum, and handles rusted or painted surfaces better. Flame is slower, only works on carbon steel, but is more economical for thick plate (over 20mm) and produces straighter edges. Choose plasma for versatility and speed; choose flame if you primarily cut thick carbon steel.
It depends on the model. Desktop units with 610×610mm cutting areas fit on a workbench. The standard 1500×3000mm table requires about 3.5m × 1.8m for the machine itself, plus additional clearance for plate loading and operator access-roughly 5m × 4m total. We can work with you on layout planning.
Most configurations come as complete units. Position the table, level it (about 30 minutes with a machinist's level), connect power and air, and you're ready to cut. We provide detailed installation guides and remote support. Most customers are cutting within a day of delivery. On-site installation is available for larger systems if needed.
Daily: Inspect consumables (e.g., electrodes and nozzles); clean the torch assembly; drain moisture from the air filter.
Weekly: Examine rails and racks for debris accumulation; verify torque on all mounting bolts.
Monthly: Lubricate linear guides and rack-and-pinion assemblies; inspect cable routing and connection integrity.
Consumable replacement remains the most frequent maintenance requirement-maintaining an on-site inventory of critical spares is strongly recommended. Implementing predictive maintenance strategies can reduce unplanned downtime by up to 50%. A comprehensive, task-specific maintenance schedule is provided with every system.
Yes, our control systems feature intuitive software with pre-set cutting parameters for various materials and thicknesses. Simply select your material and thickness, and the machine automatically adjusts cutting speed, gas pressure, and amperage. We also offer training materials and remote support. If you're familiar with a manual plasma torch or a CNC router, you'll feel at home with this equipment within a couple of days.
about Us
We specialize in manufacturing CNC cutting equipment like plasma cutters, flame cutters, combined plasma-flame systems, portable units, bench-top models, and full-size industrial worktables. Our products are shipped to numerous countries across Southeast Asia, South Asia, the Middle East, Europe, and South America.
We've exhibited at international trade shows and built a solid reputation for quality and reliability in the markets we serve. Our clientele includes steel service centers, manufacturing shops, agricultural machinery makers, metal artists, and schools. Working with these diverse industries gives us a keen insight into the real demands of metal cutting.
