Hebei Juliang Technology Co., Ltd. is one of the leading manufacturers and suppliers of lgk-65a inverter air plasma cutting machine in China. Please feel free to buy CE approved machinery made in China here from our factory. All customized machines are with high quality and competitive price.
Product Overview
The LGK-65A Inverter Air Plasma Cutting Machine is designed for mild steel, stainless steel, and non-ferrous conductive metals. Applications include:
Handheld cutting in small fabrication shops
Integration with CNC gantry cutting systems
Built on Hebei Juliang's ten-plus years of manufacturing experience in cutting equipment, this model balances portability with workshop-grade performance.
Complete Technical Specifications
|
Parameter |
Value |
|
Rated input voltage |
220V / 380V, 3-phase |
|
Rated input capacity |
11 kVA |
|
Rated output current |
65 A |
|
Maximum output voltage |
140 VDC |
|
Open circuit voltage (OCV) |
265 V |
|
Duty cycle @40°C |
100% |
|
Quality cut thickness (mild steel) |
3 – 14 mm |
|
Maximum severance (mild steel) |
25 mm |
|
Cutting speed (20 mm mild steel) |
500 mm/min |
|
Plasma gas |
Compressed air only |
|
Torch length |
7 meters |
|
Weight |
30 kg |
|
Dimensions (L×W×H) |
680 × 370 × 600 mm |
|
Insulation class |
F |
|
Enclosure protection |
IP21S |
|
Core components |
PCB board, wire coil, solenoid valve (industrial grade) |
|
Packaging |
Fumigation-free wooden crate |
Technical Features & Operating Principles
Forced air cooling for power supply + air-cooled torch
Power components derated for continuous operation
Verified at 40°C ambient temperature - not a calculated value
2 Non-Contact Pilot Arc
Arc initiates without touching the workpiece
Works on painted, rusted, or uneven surfaces
Reduces electrode wear and extends nozzle life
3 Dual-Voltage Input
Automatically accepts 220V or 380V 3-phase
No electrical modification required when moving between sites
CNC Integration Guide
The LGK-65A Inverter Air Plasma Cutting Machine includes arc voltage output signals for direct connection to CNC height controllers.
|
Signal Ratio |
Application |
|
1:1 |
System default - general CNC |
|
1:20 |
High-voltage input controllers |
|
1:50 |
Selected imported controllers |
|
1:100 |
Long-distance signal transmission |
Wiring diagrams and parameter settings are provided in Section 6 of the user manual. Custom signal interfaces available upon request.
Manufacturing & Quality Assurance
Each LGK-65A goes through the following process at Hebei Juliang's expanded facility (2025 relocation):
|
Step |
Description |
|
1. Component inspection |
100% testing of PCB, coil, solenoid valve |
|
2. Assembly |
Laser cutting, gantry milling, precision collimators |
|
3. Burn-in test |
100% full-load test (minimum 2 hours) |
|
4. Final inspection |
Mechanical test report + factory video (available to customer) |
Company Certifications & Status
CE certified
Multiple invention and utility model patents
High-tech enterprise
Hebei Province science and technology SME
Third factory expansion completed in 2025 - designated as large-scale enterprise and specialized/refined/innovative enterprise
Customer Performance Data (One Example)
|
Metric |
Previous Machine |
LGK-65A Inverter Air Plasma Cutting Machine |
|
Duty cycle |
60% |
100% |
|
Daily output (8 hours) |
80 pieces |
108 pieces |
|
Nozzle replacement interval |
2 weeks |
5 weeks |
|
Cost per cut |
Baseline |
~28% lower |
Source: Steel fabrication shop in Southeast Asia, after 4 months of continuous operation.
Frequently Asked Questions
Q: Can this machine cut stainless steel and aluminum?
A: Yes. Using compressed air, quality cut range is 3–14 mm for stainless steel and 3–10 mm for aluminum.
Q: Is the packaging suitable for sea freight?
A: Yes. Fumigation-free wooden crate. Stacking and vibration tested before shipment.
Q: Does high altitude or high ambient temperature affect the duty cycle?
A: The duty cycle is rated at 40°C / below 1000m altitude. Above these conditions, a 15-minute natural cooling period every 2 hours is recommended.
Q: Do you offer OEM or customization?
A: Yes. Panel labeling, packaging, and signal interfaces can be customized. Minimum order quantity discussed upon request.
Q: Is the LGK-65A Inverter Air Plasma Cutting Machine suitable for both handheld and CNC use?
A: Yes. The same unit supports handheld cutting now and can integrate with a CNC gantry system later when you scale up.
Technical Support & Downloads
Mechanical test report (available upon request)
Factory video inspection (available before purchase)
24/7 remote video support - multiple engineers on call
You May Also Like
High-Performance CNC Plasma Cutting Machine for Miesen (marketing one-pager)
CNC Gantry Cutting Table for Automation
Plasma Torch Consumables Kit (5-pack)
Contact & Sample Testing
Free sample cutting: Send your material to the factory or visit the showroom. Cutting edge photos and parameter records provided.
Remote support: Engineering team provides 24-hour video guidance.
Quote requirement: Material type + thickness + typical daily runtime.
