Hebei Juliang Technology Co., Ltd. is one of the leading manufacturers and suppliers of laser rust cleaning equipment in China. Please feel free to buy CE approved machinery made in China here from our factory. All customized machines are with high quality and competitive price.
Our Laser Rust Cleaning Equipment offers non-contact method for surface treatment. It employs a concentrated fiber laser beam to effectively eliminate rust, paint, oil stains, oxides, and other surface contaminants from metal.
The operator guides the handheld scanner head, which weighs between 0.75 and 1.5 kilograms, over the surface. The laser precisely vaporizes contaminants without harming the underlying metal. The system runs on a standard power supply, with most units operating on single-phase 220V and higher-power models using three-phase 380V. The laser source, cooling, and control systems are all neatly housed within a portable enclosure.
Key components include the fiber laser source, which generates the beam, and the handheld cleaning head used to direct it onto the surface. These are linked by a fiber optic cable, typically 5 to 20 meters long. A user-friendly control interface with a touchscreen display allows for easy adjustment of power, scanning speed, and cleaning modes.
Compact Integrated Frame
The entire frame is constructed from thick, cold-rolled steel and undergoes full stress relief after welding. This compact design saves nearly 40% of floor space compared to split water-cooled models. You can easily move the machine even in tight workshop aisles or temporary sites without needing to disassemble major components. It stays structurally sound over years of daily use, ensuring the laser's light path alignment remains precise.
Only the laser protective lenses and dust filters are regular consumables, lasting 3–6 months with typical use. We've eliminated complex water pipelines that are prone to clogging or leaks. Most daily maintenance simply involves dusting the lens.
We use certified domestic fiber laser generators known for their stable light output. The equipment only uses power when actively cleaning, avoiding constant high-load standby. For continuous factory operations, this significantly reduces monthly electricity costs compared to plasma cleaning systems.
One technician can set up, wire, and calibrate the light path in under 2 hours. No permanent foundation or special drainage is needed. Businesses with limited space can position it next to cutting or bending equipment without disrupting current production.
| Parameter Item | Specification | Supplementary Note |
|---|---|---|
| Laser Power | 1500W / 2000W / 3000W | 1500W for light rust; 3000W for thick heavy oxide layers |
| Cooling Mode | Air Cooling | No water tank, easy outdoor mobile operation |
| Cleaning Width | 0–100mm Adjustable | Adjust spot size for narrow seams or large flat panels |
| Operating Weight | 170kg | Single person can transport short distances |
| Continuous Working Time | 8h | Supports daily factory shift production |
| Applicable Metal | Carbon Steel, Stainless Steel, Aluminum, Copper | Not fit for transparent plastic, thin fragile non-metal parts |
FAQ
Q: What's the core working principle of laser rust cleaning equipment?
A: High-energy laser beams hit rust layers instantly, vaporizing oxides through thermal expansion. The base metal absorbs far less laser energy, so it stays intact. No abrasive or chemical media needed during the whole process.
Q: How does laser cleaning compare with traditional sandblasting derusting?
A: Sandblasting leaves surface pits and generates tons of dust waste. Laser cleaning keeps base metal smooth and cuts waste processing fees, though its single-piece processing speed is slower for ultra-large thick rust blocks.
Q: Can this cleaner work outdoors at construction sites?
A: The air-cooled design removes bulky water tanks, so it works for temporary outdoor jobs. Avoid operating under heavy rain; cover the main cabinet with waterproof cloth in humid open-air environments.
Q: Do you provide on-site installation engineers for overseas orders?
A: We offer free remote video debugging worldwide. Paid on-site engineer dispatch is available for bulk orders above 10 units, covering all training and equipment calibration on your production line.
Q: Is custom laser power or cleaning gun length supported?
A: Yes, we adjust laser power from 1500W to 3000W and extend gun cables from 5m to 10m per customer request. Custom orders take 7–15 production days based on quantity.
